ASHRAE Psychrometric Calculator

An ASHRAE psychrometric calculator helps you check moist air with ease. It can find key air data from a few simple inputs. You can use it for HVAC work, room design, cooling plans, and air flow checks.

This free tool uses ASHRAE-based air formulas. It can show humidity ratio, RH, dew point, wet bulb, enthalpy, and more. Think of it as a quick map for moist air. Enter the air data, and the tool fills in the rest.

ASHRAE Psychrometric Formula

The calculator first finds the vapor pressure of water in air. It uses the ASHRAE Hyland-Wexler method for this step.

The main humidity ratio formula is:

W = 0.621945 × pw / (p − pw)

Here, W is the humidity ratio. pw is water vapor pressure. p is air pressure.

For moist air enthalpy, the tool uses:

h = 1.006t + W(2501 + 1.86t)

Here, h is in kJ/kg dry air. t is dry bulb temperature in °C.

For specific volume, it uses:

v = 0.287042 × (t + 273.15) × (1 + 1.6078W) / p

The tool also finds air density with:

ρ = (1 + W) / v

These formulas help turn basic air data into useful HVAC results.

How to Use Online ASHRAE Psychrometric Calculator Step by Step

1. Enter the dry bulb temperature. Pick °C or °F.
2. Pick a second air value. You can use RH, wet bulb, dew point, or humidity ratio.
3. Enter air pressure. You can also enter altitude. The tool then finds pressure from altitude.
4. Click the calculate button. The tool checks your data first.
5. Read the results. You can see RH, humidity ratio, dew point, wet bulb, enthalpy, volume, density, and vapor pressure.

The tool also checks for bad air states. For example, wet bulb can't be higher than dry bulb. Dew point can't be higher than dry bulb.

Example ASHRAE Psychrometric Calculation

Let’s use a simple HVAC example. Say the air has a dry bulb temperature of 40°C. The wet bulb temperature is 20°C. Air pressure is 101.325 kPa.

The tool finds a humidity ratio near:

W = 0.0065 kg/kg dry air

That equals about 6.5 g/kg dry air.

The air enthalpy is near:

h = 56.7 kJ/kg dry air

The dew point is near:

td = 7°C

The RH is near:

RH = 14%

The specific volume is near:

v = 0.896 m³/kg dry air

So, hot air can still hold quite little water when its RH is low. It’s like a dry sponge. The air can take in more moisture before it reaches the dew point.

Final Verdict

An ASHRAE psychrometric calculator makes moist air work much easier. You don’t need to read a full chart for each case. Enter two air values and pressure. Then check the full air state.

Our ASHRAE psychrometric calculator online free tool is easy to use. It suits HVAC design, air systems, cooling work, and basic engineering checks.

FAQs

What does an ASHRAE psychrometric calculator do?

It finds key moist air values. These include RH, humidity ratio, dew point, wet bulb, enthalpy, and specific volume.

Is the ASHRAE psychrometric calculator online free?

Yes. You can use an ASHRAE psychrometric calculator free for quick air property checks.

What inputs can I use?

You can use dry bulb with RH, wet bulb, dew point, or humidity ratio. You also need air pressure or altitude.

What is humidity ratio?

Humidity ratio tells you how much water vapor sits in dry air. The result often uses kg/kg dry air or g/kg dry air.

What is dew point?

Dew point is the temperature where air reaches saturation. If air cools below it, water can start to form.

Why does pressure matter?

Air pressure changes the link between vapor pressure and humidity ratio. That’s why the calculator lets you enter pressure or altitude.
