Front To Back Ratio Antenna Calculator

A Front To Back Ratio Antenna calculator helps you check antenna signal focus. It compares front power with back power. A high ratio means less signal goes to the rear.

This tool can use power or field data. It can also find a missing value. You only need a few values. The result comes in dB.

What is the Antenna Front-to-Back Ratio?

The antenna front-to-back ratio shows the gap between front and rear signal levels. In simple terms, it tells you how much an antenna favors the front over the back.

A 20 dB ratio means the front power is 100 times the back power. A higher dB value usually means better rear signal rejection.

Front To Back Ratio Antenna Formula

For power, use: F/B = 10 × log10(PF / PB)

PF means front power. PB means back power.

For field strength or voltage, use: F/B = 20 × log10(EF / EB)

EF means front field or voltage. EB means back field or voltage.

Use the same unit for both values. This keeps the ratio correct.

How to Use the Online Front To Back Ratio Antenna Calculator

1. Pick the power mode or field mode.
2. Enter the front value.
3. Enter the back value.
4. Pick the right unit for both values.
5. Click calculate and read the F/B result in dB.

You can also use the solve mode. Enter the target F/B value and the known front or back value. The tool can find the missing value.

Example Front To Back Ratio Antenna Calculation

Say the front power is 100 W. The back power is 1 W.

First, find the power ratio: 100 / 1 = 100

Then use the formula: F/B = 10 × log10(100)

F/B = 20 dB

So, the front-to-back ratio is 20 dB.

Think of it like a loud voice in front and a soft voice behind the antenna. The front signal is much stronger.

Related Questions

How do I calculate the SWR ratio?

SWR isn't the same as front-to-back ratio. SWR checks how well power moves between a feed line and an antenna.

A common SWR formula is: SWR = (1 + |Γ|) / (1 − |Γ|)

So, don't use SWR in place of the F/B formula.

How to calculate antenna gain in dBi?

Antenna gain in dBi is a separate value. It compares antenna strength in a set path with an ideal isotropic source.

Gain and F/B ratio can both help judge antenna performance. But they measure different things.

What is a good axial ratio?

Axial ratio shows the shape of a radio wave. For circular use, a value near 1 dB is very good. A value of 3 dB is often used as a key limit for circular polarization.

Axial ratio isn't the same as F/B ratio.

Front to Back Ratio Antenna Calculator Free

Our Front to back ratio antenna calculator free tool makes this check quick. It supports power values and field or voltage values. It also lets you solve for a missing front or back value.

Final Verdict

The Front To Back Ratio Antenna calculator saves time. It uses the right log rule for power and field data. Enter matching units for the front and back values.

A higher F/B value means stronger front focus and less rear response. Use this value with gain, SWR, and axial ratio for a fuller antenna check.

FAQs

What does a 20 dB front-to-back ratio mean?

It means the front power is 100 times the back power.

Can I use watts and milliwatts together?

No. Use the same unit for both values before you calculate the ratio.

What is the formula for antenna front-to-back ratio?

For power, use F/B = 10 × log10(PF / PB). For field or voltage, use F/B = 20 × log10(EF / EB).

Is front-to-back ratio the same as antenna gain?

No. F/B compares front and rear response. Gain shows how well an antenna sends or receives energy in a direction.

Can the calculator find a missing value?

Yes. It can solve for the front or back power, field, or voltage from a target F/B value.
